Leasing of Kinglink 46'' x16' Vibrating Grizzly Feeder

Gator type 46'' x 16' Vibrating Grizzly Feeder

Standard Features:

- Welded, stress-relieved steel box.

- 3/4" Bolt-on AR steel side liners.

- 3/4" Bolt-on AR steel feeder pan liners.

- Reinforced under pan tub.

- Welded spring supports with heavy-duty coil springs.

- Outboard front and rear springs mountings.

- Unbalanced, counter-rotating vibrator unit shafts.

- Heavy-duty, spherical, self alining roller bearings.

- Oil bath shaft and bearing lubrication.

- Sight of glass oil gauge.

- Helical timing gears.

- 11" deep bolted and tapered grizzly bars with fines deflectors.

- Parts included: pivot base motor mount, spring pads and springs.

Specifications:

- Width: 46"

- Length: 16' (192")

- Pan length: 10'

- Grizzly bar length: 71.65"

- Number of bars: 8

- Maximum feed size: 24"

- Capacity: 100-400 TPH

- Required horsepower: 25 HP 1800 RPM

- Eccentric shaft speed : 500-800 RPM

- Bearings: 90mm SKF

- Driven sheave: 20.5 PD

- Drive sheave: 9.0 to 9.5 PD (Optional - not standard equipment)

Freight Dimensions:

- Width: 6'

- Length: 16' 6"

- Height: 3' 8"

- Weight: 12,600 lbs. (excluding motor)

Optional Features:

- Electric motor.

- Motor drive sheave/bushing.
