Semi-trailers KÖGEL

Kögel GmbH is a German manufacturer specializing in semi-trailers with a focus on lightweight construction and payload optimization. The product range includes curtainsiders like the Kögel Cargo, platform semi-trailers, and specialized units such as the Port 45 Triplex container chassis, which features a tare weight of approximately 5,200 kg and can handle containers from 20 to 45 feet.

Kogel trailers for sale: chassis innovation

The engineering of Kogel semi-trailers centers on chassis durability and reduced tare weight. Key to this is the in-house developed KTA trailer axle, an integrated system designed for superior tracking, low maintenance, and a weight of around 385 kg per axle assembly. The chassis frame employs high-tensile strength S700 steel and features a modular construction, allowing for standardized components to be used across different model families, from standard platform trailers to specialized reefer units.

NOVUM generation and body specs

The NOVUM generation represents a significant redesign of Kogel's platform semi-trailers, including the Cargo, Mega, and Lightplus series. The primary innovation is the Phoenixx weight-optimized frame, which utilizes extensive perforations in the steel I-beams to reduce weight by up to 130 kg compared to previous models, directly increasing the available payload. The NOVUM chassis incorporates a new external frame profile with Vario-Fix lashing points, providing nearly continuous lashing options for enhanced load securing. Body specifications often include a clear internal height of 2,700 mm for the Cargo series and up to 3,000 mm for the Mega series, meeting high-volume transport requirements.

Kogel price analysis in Europe

The European market for Kogel semi-trailers reflects a spectrum of price points contingent on vehicle age, condition, and specific equipment. Factors influencing valuation include the trailer generation (e.g., NOVUM vs. pre-NOVUM), axle condition (specifically the KTA trailer axle), and the presence of value-added certifications or features like the Kögel MCS (Multi-modal Combined System) for rail transport compatibility.

Used Kogel trailers: budget guide

The acquisition cost for used Kogel semi-trailers typically falls within the €8,000–€25,000 range. A late-model curtainsider (3-5 years old) from the NOVUM generation might command a price between €18,000 and €25,000, whereas older units or those requiring axle refurbishment are available from €8,000. Specialized units like refrigerated trailers or tippers maintain a higher residual value due to their complex systems and robust construction.

New Kogel trailers: factory pricing

Factory-new Kogel semi-trailers are priced from €30,000–€55,000 and upwards, depending heavily on the configuration. A standard Kögel Cargo trailer starts around the €30,000 mark. Customizations such as a lifting roof, additional lashing points, specific tire manufacturers, or advanced telematics systems can increase the final price significantly, with highly specialized refrigerated or container chassis units exceeding €55,000.

Nano-ceramic coating and Strong & Go

Kogel implements an advanced surface treatment process for long-term corrosion protection. The entire vehicle frame is treated with a nano-ceramic plus KTL (cathodic dip-paint) coating, also known as KTP. This technology provides a zinc-phosphate-like layer that ensures superior paint adhesion and comprehensive corrosion resistance, even in cavities and on edges. In parallel, the optional Strong & Go body structure conforms to DIN EN 12642 Code XL certification. This certification verifies that the body—including the front wall, stanchions, and side curtains—can withstand specific dynamic forces, often eliminating the need for additional lashing for form-fit loads and speeding up loading cycles.

Buying Kogel via Truck1 specialized site

Truck1.eu functions as a specialized B2B marketplace connecting buyers with a network of European dealers offering a wide inventory of Kogel semi-trailers. The platform provides detailed listings that specify key technical data, including tare weight, axle manufacturer (e.g., KTA), and body certifications like DIN EN 12642 Code XL. This allows for direct comparison of different generations and models, from the weight-optimized Phoenixx chassis to earlier robust designs.

The platform's filtering capabilities enable users to isolate units based on specific criteria such as manufacturing year, axle configuration, and price range. If you cannot find a specific configuration, you can submit a targeted request through our I'm looking for form.
